1
Audio Link LED
button
Turns the audio link between remote and base on and off.
2
Push-to-Talk
(PTT) button
Keys up the communications radio.
3 Rocker switch
1. Adjusts listen sensitivity in 2-dB steps.
2. Places the remote into Subscription Mode when pressed and held in either the
Up or Down position.
4
Quick
Disconnect (QD)
Connects to headset.
NOTE Single Channel QD shown. Connection may vary but function is the same.
5 Battery pack Powers remote.
6
Momentary/
Locking PTT
selector
Enables or disables locking operation of the PTT button.
7
Spare battery
pack
Swap batteries regularly to maximize battery life.
Be safe
Please read the safety guide for important safety, charging, battery and regulatory information
before using your new device.
Overview
Remote overview
4
