Polyaire Zonemaster Variable Air Volume - Default Chapter; Table of Contents

CONTENTS
Features 1
Application 1
Components 2
Conguration 3
Installation 5
 BypassControl 7
Commissioning 8
 1.InitiatingandExitSettingProcess 8
2. Initialisation of Touchpad Address 9
 3.RoomTemperatureSensor 9
4. Minimum Ventilation 10
 5.SupplyAirSafetyHigh&LowLimits-MasterTouchpad 10
 6.Spill/BypassAirSetpoint-MasterTouchpad 11
 7.NamingZones-MasterTouchpad 12
8. Damper on/off Test 12
 InstallationInformationSheet 13
TroubleShootingGuide 15
User Manual 16
 1.ZoneTouchpad 16
2. Master Touchpad 17
 3.ProgrammingMode 18
AppendixA-TechnicalSpecications 25
AppendixB-StandardCongurationofVAVSystem 27
Liability
Please read the instructions carefully before installing this
Zonemaster VAV Climate Control System. Polyaire Pty Ltd does
not accept any responsibility for loss or damage that may occur
as a result of the incorrect installation of this system.
