Polyaire Zonemaster Variable Air Volume - Appendix B - Standard Configuration of VAV System

Page 27
Code Items
NumberofZones
1 2 3 4 5 6 7 8
7150 Main Controller 1 1 1 1 1 1 1
7151 Master Touchpad 1 1 1 1 1 1 1
7152 Zone Touchpad 1 2 3 4 5 6 7
7154 24VTransformer 1 1 1 1 1 1 1
7186 Supply Air Sensor 1 1 1 1 1 1 1
7158 ControlCableKit 2 3 4 5 6 7 8
7159 DataCableKit 2 3 4 5 6 7 8
7093 Damper Controller* 1 1 1 1 1 1 1
7094 Control Cable 3M* 1 1 1 1 1 1 1
APPENDIX B -
STANDARD CONFIGURATION OF VAV SYSTEM
Code Items
NumberofZones
9 10 11 12 13 14 15 16
7150 Main Controller 1 1 1 1 1 1 1 1
7151 Master Touchpad 1 1 1 1 1 1 1 1
7152 Zone Touchpad 8 9 10 11 12 13 14 15
7154 24VTransformer 1 1 1 1 1 1 1 1
7186 Supply Air Sensor 1 1 1 1 1 1 1 1
7158 ControlCableKit 9 10 11 12 13 14 15 16
7159 DataCableKit 9 10 11 12 13 14 15 16
7093 Damper Controller* 1 1 1 1 1 1 1 1
7094 Control Cable 3M* 1 1 1 1 1 1 1 1
7155
24VTransformer
PlugIn
1 1 1 1 1 1 1 1
7157 DC Power Supply 1 1 1 1 1 1 1 1
* Option for bypass control system
REFER VAV SINGLE ZONE
