Polyaire Zonemaster Variable Air Volume - Components

COMPONENTS
1) Main Controller
The main controller collects and processes all the information.
2) Master Touchpad
6buttontouchpad.
  Toprogramandcontrolallthezonesinthesystem.  
3) Zone Touchpad
3buttontouchpad.
4) Bypass Damper and Controller (optional) Green
Dampercontrollerreceivesbypasscontrolsignalfromthe 
  maincontrollertoopenorclosethebypassdamper.
5) Supply Air Sensor
Supplyairsensormeasuresthetemperatureofthesupplyair.
6) Power Supply
The24VACtransformerprovidespowertotherst8touchpads
- dampers and main controller.
7) Battery
3.6Vrechargeablebatteryformaincontroller.
8) LeftLatchedDoubleAdaptor&CableKit
Double adaptor connects the main controller/touchpads via the
data bus.
 9) CentreLatchedTripleAdaptor&CableKit
Tripleadaptorconnectsthe24VACpowersupplyviathe 
control bus.
 10)MountingBracket
For the touchpads.
Page 2
