Patterns <pattern/>
This section defines patterns for the LED indicators. In the following table, x is
the pattern number, y is the step in the pattern.
Classes <class/>
This section defines the available classes for the LED and graphical icon
indicator types. In the following table, x is the class number, y is the identifier
of the state number for that class.
Assignments
This attribute assigns a type and a class to an indicator. In the case of the
Graphic Icon type, it also assigns a physical location and size in pixels on the
LCD display (refer to the next section). In the case of the LED type, it assigns a
physical LED number (refer to Graphic Icons <gi/> <IP_300/>, <IP_330>,
<IP_400/>, <IP_500/>, <IP_600/>, <IP_4000/>, and <IP_7000/> on page
A-83).
Attribute
Permitted
Values Interpretation
ind.pattern.x.step.y.state On or Off Turn LED on or off for this step.
ind.pattern.x.step.y.duration positive integer Duration in milliseconds for this step. 0=infinite
ind.pattern.x.step.y.colour Red or Green
(default is Red if
not specified)
For bi-color LEDs, specify color.
Attribute
Permitted
Values
Interpretation
ind.class.x.state.y.index positive integer For LED type indicators, index refers to the pattern index,
such as index x in the Patterns <pattern/> tag above.
For Graphic Icon type indicators, index refers to the
animation index, such as index y in the Animations <anim/>
<IP_300/>, <IP_330/>, <IP_400/>, <IP_500/>, <IP_600/>,
<IP_4000/>, and <IP_7000/> tag above.
