Polycom CX700 User Manual

User Guide for the Polycom CX700 IP Phone
2 - 6
2 Select Lock.
Your phone is now locked.
To unlock your phone:
1 Press the Unlock soft key.
The PIN entry screen appears.
2 Enter your PIN, then press the OK soft key.
3 If you have forgotten your PIN:
a Press the Forgot PIN soft key.
You are prompted to enter the password that you entered when you
first logged in (refer to Logging in on Your Phone on page 1-8).
If you press the Cancel soft key, the phone remains locked.
b Enter your password (using the soft keyboard), then press the OK soft
key.
c Enter a new six digit PIN twice (using the dial pad), then press the OK
soft key.
Note
Use the fingerprint reader to unlock your phone if you initially identified yourself
using the fingerprint reader. For more information, refer to Logging in on Your
Phone on page 1-8.

Polycom CX700 Specifications

Power

power over Ethernet	IEEE 802.3af Class 2
maximum power consumption	13 Watts

LCD Display

display size	5.7 inches
display type	amorphous-TFT Active-Matrix Transmissive
display resolution	320x240

Audio

frequency response	30 – 20kHz
signal-to-noise ratio	78 dB (@ 1kHz)
dynamic range	>80 dB (@ 1kHz)
total harmonic distortion + noise	<0.08% (@ 1 kHz)

Operating Environment

operating temperature range	-10°C to 40°C
relative humidity	80% max (non-condensing)
operating altitude range	-304.8 meter to 3962.4 meter

Weight and Dimensions

dimensions when not tilted	252.7 x 268.6 x 91.3 mm
dimensions when tilted up	193.2 x 268.6 x 192.1 mm
unit weight	2.1 kg
handset weight	200 g
shipping weight	2 kgs
