Polycom CX700 User Manual

User Guide for the Polycom CX700 IP Phone
3 - 10
Forwarding Calls
You can configure your phone so that all incoming calls are forwarded to
another party (known as static forwarding). You can also forward calls while
the phone is ringing (known as dynamic forwarding).
Static Forwarding
To enable call forwarding:
1 At the top of the graphic display, select the Forwarding icon to the right
of your name.
2 On the Forwarding screen, do one of the following steps:
a Select Forward to contact or phone number.
If you are forwarding to another contact or phone number, select the
contact name that you want to forward your calls.
b Select Forward to voicemail or one of my numbers.
Select the number that you want to forward your calls.
c Select Simultaneously ring any phone number.
Select the number that you want to ring simultaneously.
3 Press the OK soft key.
To disable call forwarding:
1 At the top of the graphic display, select the Forwarding icon to the right
of your name.
2 On the Forwarding screen, select Do not forward incoming calls.
3 Press the OK soft key.
Note
You may also forward calls to your voice mail. This feature requires that you have
access to Microsoft Exchange 2007.

Polycom CX700 Specifications

Power

power over Ethernet	IEEE 802.3af Class 2
maximum power consumption	13 Watts

LCD Display

display size	5.7 inches
display type	amorphous-TFT Active-Matrix Transmissive
display resolution	320x240

Audio

frequency response	30 – 20kHz
signal-to-noise ratio	78 dB (@ 1kHz)
dynamic range	>80 dB (@ 1kHz)
total harmonic distortion + noise	<0.08% (@ 1 kHz)

Operating Environment

operating temperature range	-10°C to 40°C
relative humidity	80% max (non-condensing)
operating altitude range	-304.8 meter to 3962.4 meter

Weight and Dimensions

dimensions when not tilted	252.7 x 268.6 x 91.3 mm
dimensions when tilted up	193.2 x 268.6 x 192.1 mm
unit weight	2.1 kg
handset weight	200 g
shipping weight	2 kgs
