Polycom CX700 User Manual

Using the Basic Features of Your Phone
3 - 3
— Dial the desired number using the dial pad.
The number appears in the phone number field.
The numbers will automatically dial once the complete number is entered.
You may need to press the Call soft key.
To place a call using the speakerphone:
>> Do one of the following steps:
a With the handset on-hook, press the Speakerphone key.
When you hear a dial tone, enter the desired number.
b Dial the desired number using the dial pad.
Press the Speakerphone key.
To place a call using the headset:
>> Do one of the following steps:
a With the optional headset connected, dial the desired number using
the dial pad.
Press the Headset key.
b Press the Headset key.
When you hear a dial tone, enter the desired number.
To place a call using the contact list:
Refer to Placing a Call to a Contact on page 2-14.
Answering Calls
You can answer a call in three basic ways using your Polycom CX700 IP phone:
• using the handset
• using the speakerphone
• using the headset
Call duration on an active call is monitored through a local call timer. This is
visible on the graphic display.
Note
You need to log in to answer incoming calls.
Only four simultaneous calls can be displayed on the graphic display at any time.

Polycom CX700 Specifications

Power

power over Ethernet	IEEE 802.3af Class 2
maximum power consumption	13 Watts

LCD Display

display size	5.7 inches
display type	amorphous-TFT Active-Matrix Transmissive
display resolution	320x240

Audio

frequency response	30 – 20kHz
signal-to-noise ratio	78 dB (@ 1kHz)
dynamic range	>80 dB (@ 1kHz)
total harmonic distortion + noise	<0.08% (@ 1 kHz)

Operating Environment

operating temperature range	-10°C to 40°C
relative humidity	80% max (non-condensing)
operating altitude range	-304.8 meter to 3962.4 meter

Weight and Dimensions

dimensions when not tilted	252.7 x 268.6 x 91.3 mm
dimensions when tilted up	193.2 x 268.6 x 192.1 mm
unit weight	2.1 kg
handset weight	200 g
shipping weight	2 kgs
