Living
7
7.3.1 Windows living area
Opening:  Press in the respective securing knob of the catch lever and turn the latch
by 90°.
 Open the window to the desired position. Ensure that the window does not
tilt and that both hinges – on the left and right at the window – latch in par-
allel.
The hinged window remains locked in the required position.
Closing:
 Swing open the pane carefully past 90° (horizontal) and move downwards
slowly.
 Pull the window slightly inwards, press the securing knob and swivel the
closing yoke into the holder
 Do not use any force when closing, because the hinges can otherwise be
damaged. At tightly closed windows the closing yoke of the latch lies within
the window frame.
Continuous ventilation The window can also be set to "Continuous ventilation". One closing device of
the closing yoke is fixated within the frame, the second one outside the frame.
In this position the window cannot be opened from the outside.
Fig. 7 Window and blind
1 Securing knob
2 Closing yoke
3 Catch lever
