Possl Globecar Summit - Setting Up Additional Seating

49Motorcaravan - 09/21-0 - GLO-MJ22-00EN
Living
7
7.13.1 Set up additional seating
 Pull the seat extension (Fig. 38,1) out of the two-person seat.
 Hook the backrest (Fig. 39,1) with the two clips (Fig. 39,2) into the seat
widening (Fig. 38,3).
 Remove the seat cushion (Fig. 40,1) and the chest cover (Fig. 38,2).
 Fold out the seat (Fig. 41,2) and secure it with the lock (Fig. 41,1).
 Insert the chest cover (Fig. 42,2) and place the seat cushion (Fig. 42,1).
7.13.2 Stow additional seat
The additional seat is stowed in reverse order for setting up.
Fig. 38 Pulling out the seat extension Fig. 39 Hook in backrest
Fig. 40 Remove the seat cushion Fig. 41 Fold out seat
Fig. 42 Pulling out the seat extension
1
1
2
3
1
2
1
2
1
2
