Living
7
7.12 Beds
7.12.1 Bed in the pop-up roof
Opening the pop-up roof
 Open the securing belts (Fig. 32,1).
 Set up the twist grips of the left- and right-hand locking mechanism (Fig.
33,1) and turn counter-clockwise until the locking mechanisms are loo-
sened.
 Fold the twist grip further downward and attach the locking mechanism to
the magnet (Fig. 33,2) (Fig. 34).
 Hold the grips with both hands and push the pop-up roof upwards (Fig. 35).
 The maximum load for the bed in the pop-up roof amounts to 200 kg.
 Fold in the pop-up roof before commencing the journey.
 Only use the bed in the pop-up roof if the safety guards are in position.
 Never leave small children without supervision.
 Ensure in particular with regard to small children less than 6 years of
age, that they cannot fall out of the bed.
 Switch off the reading lamps in the pop-up roof when it is folded in. Fire
hazard!
 Mount the safety guard when the persons are already in the pop-up roof.
Fig. 32 Open the securing belt Fig. 33 Releasing the locking mecha-
nisms
Fig. 34 Fastening the locking mecha-
nism
Fig. 35 Pushing up the pop-up roof
1
1
2
