Sanitary fittings
11
11.6 Bathroom unit / toilet usage
The bathroom is divided into two sections. Fig. 73 shows the toilet with wash-
basin, Fig. 74 shows the shower in the bathroom.
Using the bathroom
sections:
 Move the swing wall to the desired position (left-hand/right-hand) to use the
individual bathroom sections.
 The swing wall is secured in the left-hand and right-hand end position by
means of a magnetic holder. When using ensure that the wall latches
audibly into the end position.
The following positions are provided:
 Swing wall right-hand end position for using the toilet and the washbasin,
see Fig. 73
 Swing wall left-hand end position for using the shower, see Fig. 74
 Ensure for driving that the swing wall is fastened and secured (latches
in audibly) in the right-hand position (Fig. 73) at the magnetic holder.
While travelling ensure that the door of the bathroom unit is open and is
secured by means of the supplied bracket.
 While travelling or when not in use ensure that the shower head is
located in the corresponding fixture.
Fig. 73 Toilet with washbasin (illustra-
tion similar)
Fig. 74 Shower (illustration similar)
