45Motorcaravan - 09/21-0 - GLO-MJ22-00EN
7.8 Locking mechanism of the cupboard doors
Opening doors: Press in the push button and let it spring out.
Pull open the door.
Closing doors:
Close the door.
Press in the push button to lock.
7.9 Table (optional)
Folding out table: Pull the securing knob on the bottom of the table downwards.
At the same time turn the lower table-top and bring it into the desired posi-
tion.
7.10 Sockets living area
All the models are equipped with a 230 Volt socket. When the vehicle is con-
nected with the 230-Volt mains through the external power supply, 230 Volt
alternating current is available.
All the models are equipped with a 12 Volt socket. Further 12 Volt appliances
can be connected to the socket in the bathroom.
Fig. 29 Unlocking of table lower sec-
tion (similar to illustration)
Fig. 30 Table lower section folded out
(similar to illustration)
The maximum load of the 12-Volt sockets lies at 120 Watt.
Fig. 31 Sockets living area
