7.3.3 Hinged window with damping
Opening:  Turn the catch lever (Fig. 10,3) a quarter turn towards the centre of the
window.
 Open the hinged window to the desired position.
The damping (Fig. 11,1) holds the hinged window in the desired position.
Closing:
 Press the hinged window into the closed position.
 Turn the catch lever (Fig. 10,3) a quarter turn towards the window frame.
The locking catch (Fig. 10,2) is located on the inside of the window catch
(Fig. 10,1).
Continuous ventilation See Chapter 7.3.1.
 When opening the hinged windows, ensure that there are no torsional
forces. Open and close the hinged windows evenly.
Fig. 10 Catch lever in "closed" position Fig. 11 Hinged window with damping,
opened
