4.4.2 Battery Installation & Removal
Installation:
Push the battery into the product’s battery bin
horizontally as shown in picture below, the battery
buckle is bounced and locked when hearing “click”
sound.
Buckle is not in position,
which may result in the
battery falling during flight.
Make sure to power off the product
before removing the battery.
4.4.3 Charging
See 3.6 for charging method
4.4.4 View Power Level
Once the battery is inserted in the drone, short press the power button to view the power level of
smart battery, as shown in the picture below:
0%~25%
25%~30%
30%~50%
50%~55%
97%~100%
80%~97%
75%~80%
55%~75%
LED 1 LED 2 LED 3 LED 4 Current power level
Indicator is flashing Indicator is offIndicator is on
The discharge capacity will be weakened greatly and flight duration will reduce at a low temperature,
which is normal.
Avoid long-term running at a low temperature, otherwise, the battery life can be shortened.
Once the battery is inserted, make sure the battery buckle is bounced properly. This step is highly
important and related to flight safety.
Power Button
LED 1
LED 2
LED 3
LED 4
Buckle is in position, safe
Removal:
Firstly, press the buckle of smart battery, hold
the upper cover of battery to pull out the battery.
4.4.5 Operation Instructions of Smart Battery at High/low Temperature
When the battery temperature is ＜5°C, the App will prompt a low temperature warning of the battery, and the
battery needs to be preheated before flying.
When the battery temperature is ＞60°C, the App will prompt a high temperature warning of the battery, and the
drone will not be able to fly.
12
