20
5.5 Remote Controller Calibration
5.5.1 When to perform remote controller calibration
1. When the drone drifts automatically in one direction without any toggling of the control sticks.
2. When the drone automatically and continuously rotates in one direction.
3. When the control sticks are over-sensitive or lack sensitivity.
5.5.2 Calibration Procedure
1. Turn on the remote controller, and connect the mobile device, tap Settings in App, select
“Remote Controller Calibration”
2. Make sure the control sticks are in the middle position and do not operate it before tapping to
start the calibration.
3. Tap “Start Calibration”, then follow the on-screen instructions and toggle the sticks in all
directions until 100% is displayed in App interface, and then maximum toggle the thumbwheel
back and forth.
4. When App prompts “Calibration Succeeded”, the remote controller calibration is completed.
