4.5 Propellers
There are two types of Atom SE propellers, which are designed to spin in different directions.
Marks are used to indicate which propellers should be attached to which motors, the two blades
attached to one motor are the same.
Propeller
Marked
propeller
Install the marked
propeller blades on
marked arm
Unmarked
propeller
Install the unmarked
propeller blades on
unmarked arm
Installation Instructions Schematic Diagram of Installation
Use the the screwdriver from the package to
mount the propellers.
Hold the motor to remove the propeller blades
easier.
Make sure you attach the marked propellers to the motors of the arm with marks and the unmarked
propellers to the motors of the arm without marks. Otherwise the drone will be unable to fly.
If a propeller is broken, remove the two propellers and screws on the corresponding motor and
discard them. Use two propellers from the same package. DO NOT mix with propellers in other
packages.
Propeller blades are sharp. Handle with care. DO NOT squeeze or bend the propellers during
transportation or storage.
Purchase the propellers separately if necessary.
Stay away from the rotating propellers and motors to avoid injuries.
Please check the propeller blades immediately if there are any jitters or speedless in flight, and
timely replace the propellers if it's damaged or deformed.
Make sure the motors are mounted securely and rotating smoothly. Land the drone immediately if a
motor is stuck and unable to rotate freely. Stop flying the drone and contact support if there is any
abnormal sound with the motor.
Make sure that the propellers are installed securely before each flight. Check to make sure the
screws on the propellers are tightened.
When mount or remove the propellers, do not
put the screwdriver or other foreign materials
inside the motors, or the motor may be
damaged.
13
