1. Power button
Long press it for 2s to power on/off.
2. Power indicator
Indicate the power level or other status
of the remote controller
3. Control stick slot
One slot respectively at the left and right
side, which are used to store the sticks
4. TYPE-C interface
To charge the remote controller/connect
mobile device
5. RTH / Pause button
Long press for 1s to return to HOME
point automatically
Short press it to pause auto flight
6. Control stick
7. Foldable double antennas
8. Installation position of mobile device
To place mobile device.
9. Shoot button
Short press it to shoot one picture
10. Record button
Short press it to start/stop recording
11. Thumbwheel
Dial the thumbwheel horizontally to control
the tilt of the gimbal.
3.3 Remote Controller Diagram
9
11
10
4
8
6
7
5
2
3
1
06
