Potterton Paramount five 80 - Tables of Sensor Values

Model Para‐
mount
30
Para‐
mount
40
Para‐
mount
50
Para‐
mount
60
Para‐
mount
80
Para‐
mount
95
Para‐
mount
115
Connection values Natural gas E [H
UB
9,45 kWh/m³]
m³/h 0,59 -
3,2
0.95 -
4.0
1,06 -
5,30
1,48 -
6,10
2,22 -
8,10
2,12 -
10,10
2,65 -
12,20
Natural gas LL [H
UB
8,13 kWh/m³]
m³/h 0,69 -
3,7
1,11 -
4,7
1,23 -
6,20
1,72 -
7,10
2,58 -
9,50
2,46 -
11,70
3,08 -
14,10
Connection pressure for propane mbar min. 25 - max. 45
Propane [H
U
12,87
kWh/kg]
kg/h 0,44 -
2,33
0,70 -
2,95
0,93 -
3,89
1,09 -
4,51
1,63 -
5,98
2,33 -
7,38
2,72 -
8,94
Propane [H
U
24.64
kWh/m³]
m³/h 0,23 -
1,22
0,37 -
1,54
0,49 -
2,03
0,57 -
2,35
0,85 -
3,13
1,22 -
3,86
1,42 -
4,67
Electrical power consumption
Electrical connection V/Hz 230 V / 50 Hz
Max. electr. power consumption W 55 70 88 100 112 170 200
Heating mode Protection W 3 3 3 3 3 3 3
Dimensions
Weight of boiler kg 53 53 61 61 72 84 84
Boiler water content l 3,6 3,6 4,7 4,7 5,8 7,8 7,8
Height mm 852
Width mm 480
Depth mm 407 407 447 447 542 570 570
Connections
Gas connection 3/4" 1"
Heating flow 1"
1
1
/
2
”
Heating return 1"
1
1
/
2
”
For more information, see
Power compensation for increasing the permissible flue gas piping
lengths, page 42
3.2.4 Tables of sensor values
Tab.5 Resistance values for outside temperature sensor ATF
Temperature [°C] Resistance [Ω]
-20 8194
-15 6256
-10 4825
-5 3758
0 2954
5 2342
10 1872
15 1508
20 1224
25 1000
30 823
Tab.6 Resistance values for flow sensor KVF, drinking water sensor
TWF, return sensor KRF, Buffer sensor B41
Temperature [°C] Resistance [Ω]
0 32555
5 25339
10 19873
3 Technical specifications
16 Paramount five 30 – 115 7703046 - 01 - 23072018
