Potterton Paramount five 80 - Guidance Values for the Gas Flow Rate; Guidance Values for Injector Pressure

7.4.9 Guidance values for the gas flow rate
Tab.15 Guide values for the gas flow rate for natural gas
Model Paramount
50
Paramount
60
Paramount
80
Paramount
95
Paramount
115
Nominal input (full load) kW 50,0 58.0 77.0 95.0 115.0
Gas flow rate l/min l/min l/min l/min l/min
7 119 138 183 226 274
7.5 111 129 171 211 256
8,0 104 121 160 198 240
Operating heating value 8.5 98 114 151 186 225
H
uB
in kWh/m
3
9,0 93 107 143 176 213
9.5 88 102 135 167 202
10 83 97 128 158 192
10.5 79 92 122 151 183
11 76 88 117 144 174
11.5 72 84 112 138 167
7.4.10
Guidance values for injector pressure
Tab.16 Guidance values for injector pressure (full load)
Model Paramount 30 Paramount 40
Injector diameter for
Natural gas E (G20) mm 4,90 7,80
LPG (propane) mm 3,90 5,80
Guide values for injector pressure
(1)
G20 (15,0)
(2)
mbar 8,3 - 9,3 6.0 - 7.0
Propane mbar 8,3 - 9,3 6.0 - 7.0
CO
2
-content: see reference below
(1) At pressure at end of boiler 0 mbar, 1013 hPa, 15 °C
(2)
Values in brackets = Wobbe Index W
oN
in kWh/m
3
For more information, see
Technical data, page 15
7.4.11
Guidance values for injector pressure
Tab.17 Guidance values for injector pressure (full load)
Model Paramount
50
Paramount
60
Paramount
80
Paramount
95
Paramount
115
Injector diameter for
Natural gas E (G20) mm 7,00 7.80 9.00 8.50 10.30
LPG (propane) mm 5,80 6,20 7,20 6.50 7,40
Guide values for injector pressure
(1)
G20 (15,0)
(2)
mbar 7,2 - 7,7 6,5 - 7,5 8.0 - 9.0 13,0 - 14,0 13,0 - 14,0
Propane mbar 7,1 - 7,6 7,0 - 8,0 8,1 - 9,1 15,0 - 16,0 15,0 - 16,0
CO
2
-content: see reference below
(1) At pressure at end of boiler 0 mbar, 1013 hPa, 15 °C
(2)
Values in brackets = Wobbe Index W
oN
in kWh/m
3
7 Commissioning
54 Paramount five 30 – 115 7703046 - 01 - 23072018
