Configuration Prog. no. Level Standard value
DHW sensor
1: DHW sensor B3 | 2: Thermostat
5730 E DHW sensor B3
DHW ctrl elem Q3
0: No charging request | 1: Charging pump | 2: Diverting valve
5731 E Charging pump
Basic position DHW div valve
0: Last request | 1: Heating circuit | 2: DHW
5734 E Heating circuit
DHW separate circuit
Off | On
5736 E Off
Optg action DHW div valve
0: Position on DHW | 1: Position on heating circuit
5737 E Position on DHW
Ctrl boiler pump/DHW valve
0: All requests | 1: Request HC1/DHW only
5774 E All requests
Boiler pump at DHW
Off | On
5775 E On
Solar controlling element
1: Charging pump | 2: Diverting valve
5840 E Diverting valve
External solar exchanger
1: Jointly | 2: DHW storage tank | 3: Buffer storage tank
5841 E Jointly
Combi storage tank
No | Yes
5870 E No
Relay output QX1
0: None | 1: Circulating pump Q4 | 2: El imm heater DHW K6 | 3: Collector pump
Q5 | 4: Cons circuit pump VK1 Q15 | 5: Boiler pump Q1 | 7: Alarm output K10 |
11: Heat circuit pump HC3 Q20 | 12: Cons circuit pump VK2 Q18 | 13: System
pump Q14 | 14: Heat gen shutoff valve Y4 | 15: Solid fuel boiler pump Q10 | 16:
Time program 5 K13 | 17: Buffer return valve Y15 | 18: Solar pump ext exch K9 |
19: Solar ctrl elem buffer K8 | 20: Solar ctrl elem swi pool K18 | 22: Swimming
pool pump Q19 | 25: Cascade pump Q25 | 26: St tank transfer pump Q11 | 27:
DHW mixing pump Q35 | 28: DHW interm circ pump Q33 | 29: Heat request K27
| 33: Heat circuit pump HC1 Q2 | 34: Heat circuit pump HC2 Q6 | 35: DHW ctrl
elem Q3 | 40: Status output K35 | 41: Status information K36 | 42: Flue gas
damper K37 | 43: Fan shutdown K38
5890 C None
Relay output QX2
See
Parameters see Relay output QX1 (prog. no. 5890)!
5891 C Heat circuit pump
HC1 Q2
Relay output QX3
See
Parameters see Relay output QX1 (prog. no. 5890)!
5892 C DHW ctrl elem Q3
Sensor input BX1
0: None | 1: DHW sensor B31 | 2: Collector sensor B6 | 4: DHW circulation
sensor B39 | 5: Buffer sensor B4 | 6: Buffer sensor B41| 8: Common flow sensor
B10 | 9: Solid fuel boiler sensor B22 | 10: DHW charging sensor B36 | 11: Buffer
sensor B42 | 12: Common return sensor B73 | 13: Cascade return sensor B70 |
14: Swimming pool sensor B13 | 16: Solar flow sensor B63 | 17: Solar return
sensor B64
5930 C Collector sensor B6
Sensor input BX2
See
Parameters see Sensor input BX1 (prog. no. 5930)!
5931 C DHW sensor B31
Sensor input BX3
See
Parameters see Sensor input BX1 (prog. no. 5930)!
5932 C Buffer sensor B4
9 Settings
