Configuration of extension modules Prog. no. Level Standard value
Input value 1 H2/H21 module 3 7474 C 0
Funct value 1 H2/H21 module 3 7475 C 0
Input value 2 H2/H21 module 3 7476 C 10
Funct value 2 H2/H21 module 3 7477 C 1000
Funct input EX21 module 3
0: None | 25: Limit thermostat HC
7492 C None
Funct output UX21 module 3
See
Parameters see Funct output UX21 module 1 (prog. no. 7348)!
7498 C None
Sign logic out UX21 module3
0: Standard | 1: Inverted
7499 C Standard
Signal output UX21 module 3
0: 10 V | 1: PWM
7500 C PWM
Funct output UX22 module 3
See
Parameters see Funct output UX21 module 1 (prog. no. 7348)!
7505 C None
Sign logic out UX22 module3
0: Standard | 1: Inverted
7506 C Standard
Signal output UX22 module 3
0: 10 V | 1: PWM
7507 C PWM
Input/output test Prog. no. Level Standard value
Relay test
0: No test | 1: Everything off | 2: Relay output QX1 | 3: Relay output QX2 | 4:
Relay output QX3 Relay output QX21 module 1 | 7: Relay output QX22 module
1 | 8: Relay output QX23 module 1 | 9: Relay output QX21 module 2 | 10: Relay
output QX22 module 2 | 11: Relay output QX23 module 2 | 12: Relay output
QX21 module 3 | 13: Relay output QX22 module 3 | 14: Relay output QX23
module 3
7700 C No test
Output test P1 7713 C - - - %
PWM signal P1 7714 C
Outside temp B9 7730 C
DHW temp B3/B38 7750 C
Boiler temp B2 7760 C
Output test UX21 module 1 7780 C
Output signal UX21 module 1
0: None | 1: Closed (ooo), Open (---) | 2: Pulse | 3: Frequency Hz | 4: Voltage V |
5: PWM %
7781 C
Output test UX22 module 1 7782 C
Output signal UX22 module 1
0: None | 1: Closed (ooo), Open (---) | 2: Pulse | 3: Frequency Hz | 4: Voltage V |
5: PWM %
7783 C
Output test UX21 module 2 7784 C - - - %
Output signal UX21 module 2
0: None | 1: Closed (ooo), Open (---) | 2: Pulse | 3: Frequency Hz | 4: Voltage V |
5: PWM %
7785 C None
Output test UX22 module 2 7786 C
Output signal UX22 module 2
0: None | 1: Closed (ooo), Open (---) | 2: Pulse | 3: Frequency Hz | 4: Voltage V |
5: PWM %
7787 C
Output test UX21 module 3 7788 C
Output signal UX21 module 3
0: None | 1: Closed (ooo), Open (---) | 2: Pulse | 3: Frequency Hz | 4: Voltage V |
5: PWM %
7789 C
Output test UX22 module 3 7790 C
9 Settings
78 Paramount five 30 – 115 7703046 - 01 - 23072018
