aTTaCHing TO THE TraCTOr
Preparations on the tractor
General
Please observe the power range limits of the tractor being used.
Wheels
- Air pressure in the tractor’s rear tyres when ploughing should be 0.8
bar.
- Under difficult operating conditions additional wheel weights can be
advantageous. See the tractor manufacturer’s operating manual also.
Ballast weight
• Sufficient ballast weights are to be stacked on the front
of the tractor in order to guarantee steering and braking
capabilities.
• At least 20% of the tractor’s tare weight on the front axle.
Lifting gear
- Left and right lifting struts (4) must be of equal length.
Adjust using adjusting device (3).
- If the lifting struts on the lower link can be pinned variously, then select
the back position (H). In so doing the tractor’s hydraulic unit will not be
heavily loaded.
- Position (2) the upper link (1) according to the tractor manufacturer’s
information.
Setting-up for transportation
- Fix the lower link with the struts (5) so that the attached implement cannot
swing out during transportation.
- The hydraulic’s operating lever must be secured against lowering.
- Road transport not in “On-Land” position
Setting-up for ploughing
- Set the struts (5) so that the greatest possible sideways swing range
exists.
Hydraulic control on the lifting gear
Control position:
For mounting and dismounting the implement and for transportation.
The control position is the normal setting for the lifting gear hydraulics.
The mounted implement remains at the height (= position) set by the servo-
valve (ST).
Pull control, mix control:
Ploughing occurs with of one of the two operating modes. See chapter
„OPERATION“ for description.
