Circuit Breaker Monitor
01.4IB.48070A
A. Scope
The information in this instruction bulletin
describes the following Circuit Breaker Monitor
(CBM):
• AP.CBM.01IRIMK3 - Circuit Breaker
Monitoring Kit (Includes IRIM & EIM)
• CBM - Circuit Breaker Monitor
• AP.CBM.01IRIM - IRIM
• AP.CBM.01EIM - EIM
• CBM-HE-SENSOR - Hall Effect Sensor
B. purpoSe
The information in this instruction bulletin
is intended to provide details required to
properly install and operate the Circuit Breaker
Monitor described in Ch 1 General Information,
A. Scope.
This instruction bulletin provides:
1. Safety guidelines
2. General descriptions on the operation of
the Circuit Breaker Monitor
3. Instructions for installation
4. Wiring instructions
5. Procedure for obtaining data from CBM
6. Illustrations, photographs, and description
of the modules
The illustrations contained in this document
may not represent the exact construction
details of the monitor. The illustrations in this
document are provided as general information
to aid in showing component locations only.
All illustrations and photos are shown using
deenergized equipment.
Be sure to follow the appropriate safety
precaution while handling any of the
equipment. Failure to do so may result in
serious injury or death.
!
To the extent required, the products described
herein meet the applicable ANSI, IEEE, IEC, and
NEMA Standards; however, no such assurance
is given with respect to local codes and
ordinances which may vary greatly.
c. InStructIon BulletInS AvAIlABle electronIcAlly
For more information visit powellind.com. To
contact the Powell Service Division call
1.800.480.7273, or email
info@powellservice.com.
For specific questions or comments pertaining
to this instruction bulletin, email
documents@powellind.com with the Instruction
Bulletin number in the subject line.
