Power Electronics SD700 Series Getting Started Manual

SD700 – TOUCH-GRAPHIC DISPLAY
POWER ELECTRONICS
56
SMS SERVICE
Special messages
Active Label
Help
Y HLP
Start
Y STR
Stop
Y STP
Reset
Y RST
Notification messages
Active Label
Fault
Y FAULT
Started
Y MOTOR ON
Stopped
Y MOTOR OFF
3.4.2. Example for Query Messages
Regular query (non periodic query)
User1 sends a SMS message to the graphic display with the text:
MOTOR
The graphic display responds the following:
DRIVE01. MOTOR
sta=OFF
sp=+0.0%
Periodic query
See the following time graph:
Time
User1 Î Graphic
Display
User2 Î Graphic
Display
Graphic Display Î
User1
Graphic Display Î
User2
09:00
MOTORP
DRIVE01. MOTORP
sta=OFF
sp=+0.0%
10:00
DRIVE01. MOTORP
sta=OFF
sp=+0.0%
10:45
MOTORP
DRIVE01. MOTORP
sta=OFF
sp=+0.0%
11:00
DRIVE01. MOTORP
sta=OFF
sp=+0.0%
DRIVE01. MOTORP
sta=OFF
sp=+0.0%
12:00
DRIVE01. MOTORP
sta=OFF
sp=+0.0%
DRIVE01. MOTORP
sta=OFF
sp=+0.0%
12:15
MOTORP
DRIVE01. MOTORP
sta=OFF
sp=+0.0%
13:00
DRIVE01. MOTORP
sta=OFF
sp=+0.0%
13:15
13:20
MOTORP
DRIVE01. MOTORP
sta=OFF
sp=+0.0%
14:00
14:20
