VS65
POWER ELECTRONICS
26
PROGRAMMING KEYBOARD
4.3.9. Code 10 – Current signal selection
Measure the proportional current signal according to the load. Four options are available, as
shown in following table.
Set Value
0 1 2 3
Output current mA 0 – 10 0 – 10 4 – 10 4 – 20
Rated Value 500% 150% 500% 150%
Formula % (2) D=50Ix D=15Ix D=(500 / 16) • (Ix-4) D=(500 / 16) • (Ix-4)
Note: The analogue current is proportional to the actual load and the maximum value is 20 mA (or 10 mA) of output
current.
Ix: the measured current value (mA), D: the motor load current (%)
4.3.10. Code 11 – Display mode
0: the Current displayed is shown as the percentage of the rated current value of softstarter, i.e.
100% represents the rated current of softstarter.
XXX: the rated current of motor is setting between 1 and 1000, meanwhile the actual output
current value is displayed on the LCD.
4.3.11. Code 12 – Fault relay setting
The user may set the fault relay’s status to normal-open (0) or normal-closed (1).
4.3.12. Code 13 – Tributary address
This is used to set the slave address of field bus. For the same master, the slave address will be
unique. Refer to Field Bus Communication in Chapter 7.
4.3.13. Code 14 – Restart
When the starter is stopped due to the fault, setting Code 14 to 1 can cause the starter
automatically running after 6s delay. If it is set to 0, the starter can only be restarting after reset.
The function is only valid in the two-wire method.
4.3.14. Code 15 – Communication bus
It allows selection of communication bus between 0: MODBUS and 1: PROFIBUS.
4.3.15. Code 16 – Communication speed
This is used for selection of communication speed by MODBUS communication, the possible rang
is from 300 to 19.2k bps.
See 7.2 for information on usage.
