-15-
Example:
a) The right-hand aileron is connected to GY AILE-R, the left-hand aileron
to GY AILE-L.
b) The rudder is connected to GY RUDD-A, the steerable nosewheel to
GY RUDD-B.
- DOORS. 1 to 5:
If you select one of these functions, the appropriate output is linked to the
door sequencer. Which wheel door or valve is controlled by which door
sequencer output is left entirely up to you, but we recommend using the
Door Sequencer Assistant for the set-up process, as this will assign the
outputs correctly.
HD/FS:
- FS (Failsafe):
If a complete loss of signal occurs, affecting all receivers connected to
the system, this output moves to a previously determined position. If you
wish one or more outputs to take up a pre-determined position if the radio
link fails, select the FS option for that output.
At this point you should leave the OUTPUT MAPPING menu and select
the GENERAL SETTINGS menu, where you will find the TEACH
FAILSAFE POSITIONS menu point.
Now use the transmitter controls to move all the control surfaces, the
undercarriage and the throttle to the positions you want them to assume
if a failsafe event is triggered, then press the SET button; this action
stores the positions. You can test this setting simply by switching the
transmitter off: the servos will immediately move to the positions you
have just established.
- HD (Hold):
If a complete loss of signal occurs, affecting all receivers connected to
the system, this output remains in the last “good” (known) position.
