PowerBox Systems Mercury SRS User Manual

-06-
Primary settings:
• Signal speed: 10 ms
• PPM settings: Direct
• Failsafe: Inactive (if two receivers are in use; otherwise any setting)
Telemetry: if you wish your transmitter to receive telemetry data, connect
the TELE output of the PowerBox to the EXT input of your satellite.
- Graupner HoTT
When a HoTT system is used, the receivers should first be bound;
adjustments can then be carried out in the Telemetry menu. All receivers
require the CH-OUT-TYPE to be set to SUMD-OF-16.
• SUMD-OF-16 is present at Output 8.
• GR32: SUMD-OF-16 is present at Output S.
- Multiplex M-LINK
If you are using a Multiplex system, the B/D output at the receiver must
be set to Serial Servo Data SRXL. This can be accomplished using the
USB lead and the MPX Launcher PC program. If you connect two
receivers, the following settings must also be entered: max. hold
duration: 0.2 s and max. Failsafe duration: 0.0 s.
Telemetry: if you wish your transmitter to receive telemetry data, connect
the TELE output of the PowerBox to the SENSOR input of your receiver.
- JR DMSS
For a JR DMSS system you need receivers with an X-BUS output, e.g.
RG731BX. The receiver or receivers are first bound, then set to MODE A
at the transmitter. The X-BUS output now generates sixteen channels,
which are accessible from the iGyro SRS.
Telemetry: if you wish your transmitter to receive telemetry data, connect
the TELE output of the PowerBox to the SENSE input of your receiver.

PowerBox Systems Mercury SRS Specifications

General

Voltage	4 - 9 V
Type	Radio-Controlled (RC) Model Parts
Proper use	Airplane
Product type	Power supply
Compatibility	Jeti, Futaba, Spektrum, HoTT, M-Link, JR Propo
Product color	Black
Brand compatibility	Any brand
