Dear customer,

We are delighted that you have decided to purchase the PowerBox

Mercury SRS power supply from our range. We hope you have many

hours of pleasure and great success with your PowerBox Mercury SRS.

Product description

The PowerBox Mercury SRS is a new power management system which

combines all the experience and findings we have gained over the last few

years, together with customer requests, in a single compact unit. Never

before has so much functionality been crammed into such a small space!

The Mercury SRS is ideal for any application requiring an airborne system

which provides an uncompromising level of high performance. Integral

iGyro, dual battery, dual receiving system, telemetry, door sequencer and

servo matching are just a few of the highlights which this small, lightweight

device provides.

Introduction

These instructions explain how to install the Mercury SRS in the model

and set it up with the help of the Assistants. Working through the individual

steps in the Assistants completes most of the programming for the model;

all that remains is to set up the auxiliary functions and fine-tune the servos

using the servo-match function. Naturally it is also possible to set up all the

functions of the Mercury SRS manually, i.e. without using the Setup

Assistant. All the menu points are explained individually in the latter part of

these instructions.

1. Using the unit for the first time

Any pilot who has experience using a PowerBox will immediately feel ‘at

home’ with the method of operating the Mercury SRS. The device is

operated in the usual way with the help of a menu system displayed on the

OLED screen, and the ON / OFF switch.

1.1. Installing the Mercury SRS in the model

The Mercury SRS must be screwed to a hard surface in the model,

otherwise it is possible that the integral iGyro will not work properly. If the

mounting plate is large, it must be stiffened by the addition of cross-struts.

Please note that the Mercury SRS must always be installed in the model

Voltage	4 - 9 V
Type	Radio-Controlled (RC) Model Parts
Proper use	Airplane
Product type	Power supply
Compatibility	Jeti, Futaba, Spektrum, HoTT, M-Link, JR Propo
Product color	Black
Brand compatibility	Any brand

PowerBox Systems Mercury SRS User Manual
