PowerBox Systems Mercury SRS User Manual

-32-
10. Specification
Operating Voltage: 4.0V - 9.0V
Battery type: 2s LiPo/LiIon, 2s LiFePo, 5s NiMH/NiCd,
Current drain (ON): approx. 99mA
Current drain (OFF): approx. 3μA
Output voltage regulated: 5.9V and/or 7.4V
Max. output current: Peak 2 x 20A
Dropout voltage: 0.3V
Signal resolution: 0.5μs
Output framerate: 12ms, 15ms, 18ms, 21ms
Display: OLED 128x64 pixels, graphic
Servo sockets: 15
Channels max. 18
Telemetrie: Futaba, Jeti, Spektrum, Hott, M-Link,
JR DMSS
Size: 93x67x19 mm
Weight incl. Switch and screen: 115g
Temperature range: -30°C to +75°C
EMV approval: EN 55014-1:2006
CE approval: 2004/108/EG

PowerBox Systems Mercury SRS Specifications

General

Voltage	4 - 9 V
Type	Radio-Controlled (RC) Model Parts
Proper use	Airplane
Product type	Power supply
Compatibility	Jeti, Futaba, Spektrum, HoTT, M-Link, JR Propo
Product color	Black
Brand compatibility	Any brand
