Front and rear panels | 5

1. Mains plug

2. Air vents

3. Serial ID selector for the RS485 port

(non AESOP version only)

4. RS485 serial port (non AESOP version only)

5. AES3/analog switch for input 2

6. Input 2: channel 2 analog input in analog

mode or AES3 input in AES3 mode, according

to the position of the switch in #5

7. Link button: link input from channels 1 and 2

8. Input 1: channel 1 analog input

9. Speaker connector: output channel 1

10. Speaker connector: output channel 2

11. Ethernet+AESOP ports (AESOP version only)

12. Vext: 12 V

, 1A external voltage input (AESOP

version only)

K6, K8, K10, K20 rear panel.

K6, K8, K10, K20 AESOP rear panel.

1 2 4

5 6

7 8
