Channel Handling
Number of channels
2 in / 2 out mono,
bridgeable per ch. pair
Analog input connectors 2x XLR
Analog line output connectors 2x XLR
Speaker connectors 2x NL4MD speakON
Audio
Gain
32 dB, 30 dB, 28 dB, 26 dB,
24 dB, 22 dB, 20 dB, 18 dB,
14 dB, 4 dB, -∞, user selectable
Input sensitivity @ 8  1.4 V / +5.14 dBu
Max input level 6 V / +17.8 dBu
Frequency Response ( ±0.5 dB , 1 W @ 8 ) 20 Hz - 20 kHz
Crosstalk (1 kHz) > 70 dB
S/N ratio (20 Hz - 20 kHz A-Weighted @ 8 ) > 109 dB
Input impedance 10 k balanced
THD+N (from 0.1 W to Full Power)
< 0.02%
(typical < 0.005%)
DIM (from 0.1 W to Full Power)
< 0.02%
(typical < 0.005%)
Slew Rate (input lter bypassed @ 8 ) > 40 V/µs
Damping Factor @ 8 , 20 Hz - 100 Hz > 5000
AC Mains Power
Power supply Universal regulated switch more with PFC
Nominal voltage (±10%) 100-240 V @ 50-60Hz
Power factor (> 500 W ouput) > 0.95
Consumption/current draw @ 115 V @ 230 V
Idle 39 W 0.6 A 39 W 0.3 A
1/8 Max Output Power @ 4  283 W 3.8 A 283 W 1.9 A
1/4 Max Output Power @ 4  538 W 7 A 538 W 3.5 A
AC Mains connector
IEC C14 inlet;
region-specic power cord provided
Thermal
Operating temperature 0° - 45° C / 32° - 113° F
Cooling
Fan, continuously variable speed,
temperature controlled, front to rear airow
Thermal dissipation
Idle 133 BTU/h 33 kcal/h
1/8 Max Output Power @ 4  368 BTU/h 93 kcal/h
1/4 Max Output Power @ 4  641 BTU/h 162 kcal/h
DSP*
Architecture Analog Devices SigmaDSP® 50 MIPS
AD/DA converters Cirrus Logic® 24 bit 48 kHz
Internal precision 28 bit data path with 56 bit internal processing
Latency 1.0 ms xed latency architecture
Memory/Presets
Up to 4 local presets, unlimited via Armonía Pro
Audio Suite™ software
Delay
340 ms input delay
10 ms per channel output delay
Equalizer
Parametric IIR: peaking, hi/lo-shelving, all-pass,
band-pass, band-stop, hi/lo-pass
Crossover
Butterworth, Linkwitz-Riley, Bessel:
6 dB/oct to 48 dB/oct (IIR)
Limiters
Peak limiter, RMS limiter,
frequency dependent RMS limiter
Remote control Armonía Pro Audio Suite™ software
Networking*
Standards compliance 1x RJ45 auto-sensing 10/100 Mbps UTP port
Supported topologies star, daisy-chain, closed loop
Remote interface Armonía Pro Audio Suite™
Auxiliary supply
12 V / 1 A max for DSP management and remote on/off
via 2 pin Phoenix
2
MCV 1,5/ 2-G-3,81
Construction
Dimensions L x H x W 483 mm x 44.5 mm x 379 mm (19.0 in x 1.8 in x 14.9 in)
Weight 7.4 kg (16 lb)
Output Stage
Maximum output power per channel @ 8  360 W
Maximum output power per channel @ 4  700 W
Maximum output power @ 8  Bridged 1400 W
Maximum unclipped output voltage 85 V
peak
Maximum output current 65 A
peak
The power gure is calculated by driving and loading symmetrically all the
channels: uneven loads allow to achieve highest performance.
M14D and M14D HDSP+ETH
Specications
* Only for HDSP+ETH model.
Uniquement pour le modèle HDSP+ETH.
Sólo para el modelo HDSP.
Solo per il modello HDSP+ETH.
只为HDSP模型
Nur für HDSP+ETH Modell.

Somente para o modelo HDSP.
Specifications | 63
