INDEX
18
6.3 Main Board Disassembling
Unplug the mains’ Faston connectors.
Unclip the safety retainer from the ground connector
Proceed by removing the 3 at cables connecting the
Main Board to the DSP Board (highlighted in Orange)
T-SERIES | SERVICE MANUAL
