POWERVAR Security Plus UPS
16
BATTERY
Voltage (VDC) 96.0, nominal
109.2, float
Battery 12V, 34W flame retardant
High Rate, Sealed Lead-Acid
Quantity 16
Charge Current (ADC) 3.0
Backup Time (min) > 8.0
Recharge Time 8 Hours to 90%
ENVIRONMENT
Temperature (°C) 0 to 40, operating
-20 to 60, transit
Altitude (m) 2,000, operating
12,000, transit
Humidity 5.0% to 90.0%, non condensing
Audible (dBA) 50-55 @ 1m from front of unit
Heat Dissipation (BTU/hr) 3252
AGENCIES
EMC FCC Part 15J Class A
EN 55022 Class A/ CISPR 22
EN 50091-2
IEC 61000-3-2
Safety Agencies UL1778 4
th
Ed.
cUL to CSA22.2 No.107.1
CE:
IEC62040, w/CB report and certificate
IEC61000-4-2, Electrostatic Discharge
IEC61000-4-3, Radiated Electromagnetic Field Immunity
IEC61000-4-4, Electrical Fast Transient/ Burst Immunity
IEC61000-4-5, Surge Immunity
IEC61000-4-6, Immunity to Conducted Radio Frequency Disturbances
IEC61000-4-8, Power Frequency Magnetic Field Immunity
IEC61000-4-11, Voltage Dips, Short Interruptions, and Voltage Variations
RoHS All units are RoHS compliant
OTHER
Communication RS-232
USB
DB-9 Dry Contacts
Internal SNMP Adapter (option)
Unit Weight 317 lbs. / 143 kg.
Shipping Weight 412 lbs. / 185 kg.
Plug & Receptacle* L6-30P (2)5-20R (1)L6-30R
*Hardwire unit is standard. Plug & Receptacle is optional. Contact factory for part numbers.
NOISE REJECTION-ISOLATION: With unit under power and an ANSI/IEEE C62.41Cat. A pulse applied either normal or common mode at the input, the
noise output voltage will be less than 10V normal mode and less than 0.5V common mode in all four quadrants (CM-NM, NM-NM, CM-CM, NM-CM).
SURGE VOLTAGE WITHSTAND CAPABILITY: Tested under power to ANSI/IEEE C62.41 Cat. A & B (formerly IEEE587-1980). Cat. A - 6000V @ 200
amps, 0.5 usec risetime, 100 kHZ decay, Cat. B - 6000V @ 500 amps, 0.5 usec risetime, 100 kHZ decay.
