POWERVAR Security Plus UPS
40
All POWERVAR Hardwired Security Plus UPS system’s mains INPUT must be protected by
proper sized branch circuit breakers in the building installation. The recommended
branch circuit ratings at full rated load are listed below:
ABCDEF2000-11 35 AMP
ABCDEF3000-11 45 AMP
200-208V 220-240V
ABCDEF2000-22 20 AMP 15 AMP
ABCDEF3000-22 25 AMP 20 AMP
ABCDEF4000-22 35 AMP 25 AMP
ABCDEF5200-22 40 AMP 30 AMP
ABCDEF6000-22 45 AMP 35 AMP
ABCDEF8000-22 60 AMP 45 AMP
ABCDEF10.0-22 80 AMP 60 AMP
ABCDEF12.0-22 90 AMP 70 AMP
ABCDEF15.0-22 110 AMP 80 AMP
Refer to local and national electric codes for proper installation guidelines. The breaker
recommendations listed in the chart above are intended for installations in North America. For
international installations, please refer to the local and national electrical codes and standards.
All Powervar Hardwired Security Plus UPS system’s OUTPUT must be protected by proper sized
AC disconnect device. The recommended disconnect device ratings at full rated load are listed
below:
ABCDEF2000-11 20 AMP
ABCDEF2000-22 10 AMP
ABCDEF3000-11 30 AMP
ABCDEF3000-22 15 AMP
ABCDEF4000-22 20 AMP
ABCDEF5200-22 25 AMP
ABCDEF6000-22 30 AMP
ABCDEF8000-22 50 AMP
ABCDEF10.0-22 65 AMP
ABCDEF12.0-22 80 AMP
ABCDEF15.0-22 100 AMP
