Powtran PI500-W Series User Manual

Chapter 2 Standard specifications
9
Chapter 2
conversion attribute selection, timing pump change, etc.
Personaliz
ation
function
Self-inspection of
peripherals after
power-on
After powering on, peripheral equipment will perform safety
testing, such as ground, short circuit, etc.
Common DC bus
function
Multiple inverters can use a common DC bus
Quick current
limiting
The current limiting algorithm is used to reduce the inverter
overcurrent probability, and improve whole unit antiinterference
capability.
Timing control
Timing control function;time setting max 6500min
Runni
ng
Input signal
Running
method
Keyboard/terminal/communication
Frequency
setting
Analog setting DC 0 to 10V/0 to 20mA including adjustable , panel
potentiometer setting, Communication setting, keyboard setting.
Start signal
Rotate forward/reverse
Emergency
stop
Interrupt controller output
Wobbulate run
Process control run
Fault reset
When the protection function is active, you can automatically or
manually reset the fault condition.
PID feedback
signal
Including DC(0 to 10V), DC(0 to 20mA)
Output Signal
Running
status
Motor status display, stop, ac/deceleration, constant speed,
program running status.
Fault output
Contact capacity :Normally open contact 5A/AC 250V,1A/DC 30V.
Analog output
Two-way analog output, 16 signals can be selected such as
frequency, current, voltage and other, output signal range (0 to
10V / 0 to 20mA).
Output signal
Up to 8 output signals
Run function
Limit frequency, jump frequency, frequency compensation, auto-
tuning, PID control
DC braking
Built-in PID regulates braking current to ensure sufficient braking
torque under no overcurrent condition
Protect
ion
functio
n
Inverter protection
Overvoltage protection, undervoltage protection, overcurrent
protection, overload protection, overheat protection, overcurrent
stall protection, overvoltage stall protection, losting-phase
protection (Optional), External fault,communication error, PID
feedback signal abnormalities, short circuit to ground protection.
IGBT temperature
display
Displays current temperature IGBT
Inverter fan control
Can be set
Instantaneous power
down restart
Less than 15 milliseconds: Continuous operation
Less than 15 milliseconds: Automatic detection of motor speed,
start tracking the motor current speed
Speed start tracking
method
The inverter automatically tracks motor speed after it start
Parameter
protection function
Protect inverter parameters by setting administrator password and
decoding
Displa
y
LED/OLE
D display
keyboard
Running
information
Monitoring objects including: Running frequency, set frequency,
bus voltage, output voltage, output current, output power, output
torque, input terminal status, output terminal status, analog AI1
value, analog AI2 value, motor actual running speed,PID set value
percentage, PID feedback value percentage.
