Powtran PI500-W Series User Manual

Chapter 5 Function parameter
33
Chapter 5
5-1-6.F4 group -V/Fcontrolparameters
No.
Code
Parameter name
Setting range
Factory
setting
Chan
ge
107
F4.00
V/Fmode setting
0:Straight line V/F; 1:MultipointV/F;
2:SquareV/F; 3:1.2 time V/F
4:1.4time v/F; 6:1.6time V/F;
8:1.8time V/F;
10:V/F Completely separate
11:V/F Half separation;
0
★
108
F4.01
Torqueboost
0.0%( Automatictorque boost)0.1 to 30%
0.0%
★
109
F4.02
Promote cut-off
frequency
0.00Hz to F0.19(Maximum frequency)
15.00Hz
★
110
F4.03
V/F Frequency point1
0.00Hz to F4.05
0.00Hz
★
111
F4.04
V/F Voltage point1
0.0% to 100.0%
0.0%
★
112
F4.05
V/F Frequency point2
F4.03 to F4.07
0.00Hz
★
113
F4.06
V/F Voltage point2
0.0% to 100.0%
0.0%
★
114
F4.07
V/F Frequency point3
F4.05 to b0.04(Ratedmotor frequency)
0.00Hz
★
115
F4.08
V/F Voltage point3
0.0% to 100.0%
0.0%
★
116
F4.09
Slip compensation
coefficient
0.0% to 200.0%
0.0%
☆
117
F4.10
Overexcitation gain
0 to 200
80
☆
118
F4.11
Oscillation suppression
gain
0 to 100
0
☆
119
F4.12
V/F separation voltage
source
0 to 9
0
☆
120
F4.13
Voltage digital setting
0V to ratedmotor voltage
0V
☆
121
F4.14
Voltage rise time
0.0s to 1000.0s
0.0s
☆
5-1-7.F5 group Vector control parameters
No.
Code
Parameter name
Setting range
Factory
setting
Chan
ge
122
F5.00
Speed loop ratio G1
1 to 100
30
☆
123
F5.01
Speed loop integral T1
0.01s to 10.00s
0.50s
☆
124
F5.02
Switching frequency 1
0.00 to F5.05
5.00Hz
☆
125
F5.03
Speed loop ratio G2
0 to 100
20
☆
126
F5.04
Speed loop integral T2
0.01s to 10.00s
1.00s
☆
127
F5.05
Switching frequency 2
F5.02 to F0.19(Max. frequency)
10.00Hz
☆
128
F5.06
Speed loop integral T2
0:Invalid ; 1:Valid
0
☆
129
F5.07
Torque upper limit
source
0: Function code setting;
1:Analog AI1 setting;
2:Analog AI2setting;
3:Set panel encoder setting;
4:High-speed pulse setting;
5:Communications setting
6:Min(AI1,AI2)setting
7:Max(AI1,AI2)setting
0
☆
