Powtran PI500-W Series User Manual

Chapter 5 Function parameter
26
Chapter 5
38
F0.12
Command frequency
synchronization
Units digit: Operation panel command
binding frequency source selection
0:No binding; 1: Keypad set frequency;
2:Analog AI1 setting;
3:Analog AI2 setting
4:Keypad potentiometer setting;
8:PID setting;
9:Communication setting
Tens digit: Terminal command binding
frequency source selection (0 to 9,same
as units digit)
Hundreds digit:Communication
command binding frequency source
selection(0 to 9,same as)
000
☆
39
F0.13
Acceleration time 1
0.00s to 6500s
Depends
on models
☆
40
F0.14
Deceleration time 1
0.00s to 6500s
Depends
on
models
☆
41
F0.15
Ac/Deceleration time
unit
0:1 second; 1:0.1 second;
2:0.01 second
1
★
42
F0.16
Ac/deceleration time
reference frequency
0: F0.19(Maximum frequency)
1: Set frequency 2: 100Hz
0
★
43
F0.17
Carrier frequency
adjustment
0: NO; 1: YES
0
☆
44
F0.18
Carrier frequency
0.5khz to 16.0khz
Depends
on
models
☆
45
F0.19
Maximum output
frequency
50.00Hz to 320.00Hz
50.00Hz
★
46
F0.20
Upper limit
frequency source
0: F0.21 setting; 1: Analog AI1 setting
2: Analog AI2 setting
3: Keypad potentiometer setting
5: Communications reference
0
★
47
F0.21
Upper limit
frequency
F0.23 (Lower limit frequency) to
F0.19(Maximum frequency)
50.00Hz
☆
48
F0.22
Upper limit
frequency offset
0.00Hz to F0.19 (Maximum frequency)
0.00Hz
☆
49
F0.23
Lower limit frequency
0.00Hz to F0.21 (Upper limit
frequency)
20.00Hz
☆
50
F0.24
Running direction
0:Same direction;1: Opposite direction
0
☆
51
F0.26
AI Analog accuracy
0: 0.01Hz; 1: 0.05Hz;
2: 0.1Hz; 3: 0.5Hz
1
☆
52
F0.27
GF type
1.G type (Constant torque load type)
2.F type (Fans/pumps load type)
-
●
5-1-3.F1 group Input terminal
No.
Code
Parameter name
Setting range
Factory
Chan
