Powtran PI500-W Series User Manual

Chapter 5 Function parameter
39
Chapter 5
detection time
228
E2.13
Proportional gain KP1
0.0 to 200.0
50.0
☆
229
E2.14
Integration time Ti1
0.01s to 10.00s
1.00s
☆
230
E2.15
Differential time Td1
0.000s to 10.000s
0.000s
☆
231
E2.16
Proportional gain KP2
0.0 to 200.0
20.0
☆
232
E2.17
Integration time Ti2
0.01 to 10.00s
2.00s
☆
233
E2.18
Differential time Td2
0.00 to 10.000s
0.000s
☆
234
E2.19
PID parameter switching
conditions
0: No switching
1: Switching via terminals
2: Automatically switching according
to deviation.
0
☆
235
E2.20
PID parameter switching
deviation 1
0.0% to E2.21
20.0%
☆
236
E2.21
PID parameter switching
deviation 2
E2.20 to 100.0%
80.0%
☆
237
E2.22
PID integral properties
Units digit: integral separation
0: Invalid; 1: Valid
Tens digit: whether stop integration
when output reaches limit
0: Continue; 1:Stop
00
☆
238
E2.23
PID initial value
0.0% to 100.0%
0.0%
☆
239
E2.24
PID initial value hold time
0.00s to 360.00s
0.00s
☆
240
E2.25
Maximum deviation of
twice outputs(forward)
0.00% to 100.00%
1.00%
☆
241
E2.26
Maximum deviation of
twice outputs(backward)
0.00% to 100.00%
1.00%
☆
242
E2.27
Computing status after
PID stop
0: Stop without computing
1:Stop with computing
1
☆
243
E2.28
reserved
244
E2.29
PID automatic decrease
frequency selection
0:Invalid；1:Valid
1
☆
245
E2.30
PID stop frequency
0.00Hz to maximum frequency (F0.19)
25
☆
246
E2.31
PID checking time
0s to 3600s
10
☆
247
E2.32
PID checking times
1 to 500
20
☆
5-1-14.E3 group -Virtual DI.Virtual DO
No.
Code
Parameter name
Setting range
Factory
setting
Cha
nge
248
E3.00
Virtual VDI1
terminal function
selection
Same as F1.00 to F1.07
0
★
249
E3.01
Virtual VDI2
terminal function
selection
Same as F1.00 to F1.07
0
★
250
E3.02
Virtual VDI3
terminal function
Same as F1.00 to F1.07
0
★
