Powtran PI500-W Series User Manual

Chapter 1 Inspection and safety precautions
4
Chapter 1
protection.
3
Run over power
frequency
The inverter output frequency rang is 0Hz to 3200Hz(Max.vector
control only supports 300Hz). If the user is required to run at 50Hz
or more, please consider the endurance of your mechanical devices.
4
Vibrations of
mechanical device
Inverter output frequency may be encountered mechanical resonance
point of the load device, you can set jump frequency parameter inside
inverter to avoid the case.
5
Motor heat and
noise
The inverter output voltage is PWM wave that contains a certain
amount of harmonics, so the temperature rise, noise and vibration of
motor show a slight higher than frequency power frequency operation.
6
Output side with
piezoresistor or
capacitor for proving
power factor
The inverter output is PWM wave, if the piezoresistor for lightning
protection or the capacitor for improving power factor is installed in
the output side, which easily cause the inverter instantaneous
overcurrent or even cause damage to the inverter. Please do not use.
7
Contactor or switch
used in the inverter
input/output
terminals
If contactor is installed between power supply and inverter, the
contactor is not allowed to start/stop the inverter. Necessarily need to
use the contactor to control the inverter start/stop, the interval should
not be less than one hour. Frequent charging and discharging may
reduce the service life of the inverter capacitor. If the contactor or
switch is equipped between output terminals and motor, the inverter
should be turned on/off without output status,otherwise which easily
lead to damage to the inverter module.
8
Use other than the
ratedvoltage
PI series inverter is not suitable for use beyond the allowable operating
voltage described in this manual, which easily cause damage to the
parts inside inverter. If necessary, please use the corresponding
transformer to change voltage.
9
Never change 3-
phase input to 2-
phase input
Never change PI series 3-phase inverter to 2-phase one for application.
Otherwise it will lead to malfunction or damage to the inverter.
10
Lightning surge
protection
The series inverter is equipped with lightning overcurrent protection
device, so it has the ability of self-protection to lightning induction.
For the area where lightning is frequent, user should also install the
extra protection in the front of the inverter.
11
High altitude and
derating
application
When the inverter is used in areas over 1000m altitude, it is required
to reduce frequency because the thin air will decrease the cooling
effect of inverter. Please consult our technician for details on the
application.
12
Special use
If the user need to use methods other than the suggested wiring
diagram provided in this manual, such as common DC bus, please
consult our technician.
13
Precautions for
scrap disposal of
the inverter
When electrolytic capacitors on the main circuit and printed circuit
board as well as plastic parts are burned, it may produce toxic
gases.Please disposing as industrial waste.
14
Adaptive motor
1) Standard adaptive motor shall be four-pole asynchronous squirrel-
cage induction motor . Apart from the said motors, please select the
inverter according to the motor rated current.
2)The cooling fan and the rotor shaft for non-inverter motor are
coaxially connected, the fan cooling effect is reduced when the
rotational speed is reduced, therefore, when the motor works in
overheating occasions, a strong exhaust fan should be retrofitted or
replace non-inverter motor with the inverter motor.
3) The inverter has built-in the adaptive motor standard parameters,
according to the actual situation, please identify motor parameters or
accordingly modify the default values to try to meet the actual value,
