■ 3 Set up
16
3.6 Safety measures
The safety class 1 instrument, the moisture analyser, may only be
plugged into a socket which has been installed in accordance with
regulations and is fitted with a protective earth terminal. The safety
effect may not be undone by using an extension lead without an earth
wire. If the voltage is coming from mains supplies without a protective
earth terminal, arrange for an electrician to create a comparable level
of protection in accordance with valid installation regulations.
3.7 Levelling
In order to function properly, the moisture analyser must be precisely
horizontal.
The instrument is fitted with a "levelling bubble" and two rotatable
feet for level-control, with the aid of which it is possible to
compensate for small height differences and/or unevennesses in the
surface on which the instrument is standing.
The two screw feet must be adjusted so that the air bubble is
precisely in the center of the sight glass of the levelling bubble.
Incorrect Correct
NOTE
The instrument must be carefully relevelled each time it is moved in
order to obtain accurate measurements.
