COMMERCIAL PRODUCTS DIVISION
You do not need any special knowledge or experience to set up the EFX. However,
because of the size and weight of the EFX, you will need to obtain appropriate
assistance during assembly.
INSTALLATION REQUIREMENTS
Follow these installation requirements when installing the EFX.
If you do not
install the EFX according to the following guidelines, you could void the Precor
Limited Warranty.
• Set up the EFX on a solid, flat surface. Unpack and assemble the EFX close to
where you’ll use it. Make sure that the flat surface under the unit is smooth and
level. A level unit is required for the user’s safety and for proper operation.
• Provide ample space around the unit. Open space around the unit makes
for a safer mount and dismount.
• Fill out and mail the limited warranty card. The serial number is located on
a label at the rear of the unit near the optional battery recharger receptacle.
Write the serial number onto the Precor Limited Warranty card found on the
back cover of this manual. Refer to
Obtaining Service
on page 5 and write the
number there as well.
ASSEMBLY INSTRUCTIONS
To assist you in the assembly, the items in the Hardware kit, shown in Diagram 2,
correspond to a particular letter in the alphabet. These letters appear throughout the
assembly instructions. Refer to Diagram 2 on page 10.
1. Unpack the EFX546. Remove the packing materials and loose contents (up-
right support with display console, upright support bracket covers, split rubber
grommet, hardware kit, and handrails) from inside the cardboard pockets and
from around the base frame assembly.
2. Pull the large cardboard piece away from the base frame assembly. Ask
for assistance to move the EFX off the shipping pallet. You may need to cut
the tie wraps that hold the base frame and roller arms to the pallet.
3. Move the unit to the location where you plan to use it. Once you attach
the handrails, the EFX is difficult to move through a standard door frame.
Make sure that you assemble the unit where it will not have to be moved
through any doorways.
CAUTION: Do not assemble the EFX if it is plugged into its optional
battery recharger.
Setting Up the EFX
®
