page 22
COMMERCIAL PRODUCTS DIVISION
USING CSAFE STANDARD EQUIPMENT
The EFX546 is fully compatible with CSAFE protocols. Once the unit is con-
nected to a CSAFE master device and the user maintains a stride rate above 40
strides per minute, the user is prompted to enter a user ID.
Note: If the optional battery recharger is plugged into the EFX and connected to
an appropriate power source, then no pedaling is necessary for user ID entry.
Five zeros appear on the display. The left zero indicates that it is awaiting input.
The following table provides information about the keypad functions:
User ID Entry: Program Keys
or moves the blinking LED from field to field.
Numeric keypad use the number keys to enter a user ID. The number that is
pressed appears in the display and the next field begins to
blink. When all five user ID numbers are selected, the user
must press Enter to submit it.
Enter submits the displayed user ID. Note that if the five zeros
are being displayed when the user presses Enter, the user
ID entry is bypassed and the Course prompt appears.
Reset resets the display to the Precor banner.
A message indicates when the user ID is accepted by the CSAFE master device.
Then, the course prompt is displayed. See
Quick Steps to Working Out
on page 31.
Note: If the user’s stride rate drops below 40 strides per minute while using the
CSAFE device connection, a prompt PEDAL FASTER appears. If the stride rate
remains below the 40 strides per minute threshold for the next twenty seconds,
the CSAFE connection is terminated. The word RESETTING appears on the
display while the EFX disconnects from the CSAFE device.
To review information about CSAFE specifications, visit the web site at:
www.fitlinxx.com/csafe
The EFX supports the CSAFE master device per the specifications found at the
web site. Two exceptions exist:
GoInUse (0x85) and GoFinished (0x86)
Additional CSAFE2 commands supported by the EFX546 software include:
SetGear, SetGrade, SetProgram, SerUserInformation, GetUserInformation,
GetOdometer, and GetErrorCode, SetHRZone, GetHRTZone, GetHRAvg,
GetHRMax, GetTemperature, and GetVoltage
If you have questions or need technical support, refer to
Obtaining Service
on
page 5.
