COMMERCIAL PRODUCTS DIVISION
Diagram 12
Level the unit.
Rear crossbar
Rear casing
Adjustable rear foot
15. Level the unit. Diagram 12. The unit has adjustable rear feet that can help
level the unit plus or minus 1/4-inch. To rotate the adjustable rear feet, have an
assistant stand in front of the display console and face the rear feet. Ask the
assistant to grasp the upper handrails on either side of the display console
and pull toward him or her. The rear feet should lift off the floor which will let
you rotate the rubber feet in the necessary direction.
SUPPLYING POWER TO THE EFX546
The EFX does not require an electrical power connection. It has an internal battery
that is recharged every time a user works out for a reasonable period of time. A
pedaling speed above 40 strides per minute must be maintained for several seconds
before the Precor banner appears on the display. Once the banner appears, the user
can press QuickStart or Enter to begin working out. For more information, refer to
page 30, Exercising on the EFX .

Precor EFX546 Specifications

Mechanical Specifications

cross ramp angle	13 - 40 degrees (adjustable)
stride length	18 inches (46 cm)
resistance levels	1 - 20

Materials and Construction

frame	Powder-coated steel

Weight and Dimensions

length	80 inches (203 cm)
width	30 inches (76 cm)
height	62 inches (156 cm)
weight	230 lbs (105 kg)
shipping weight	340 lbs (155 kg)
