page 9
COMMERCIAL PRODUCTS DIVISION
Thank you for purchasing the self-powered Precor EFX
®
546. Built to the exacting
standards of the health club environment, the EFX is intended for commercial
use and can withstand the rigors of daily club use with little maintenance.
Important: Before using the EFX, we urge you to familiarize yourself and your
staff with the entire Owner’s Manual. Understanding this manual will help you and
your customers use the EFX safely and successfully.
Your EFX is carefully inspected before shipment so it should arrive in good operat-
ing condition. Precor ships the unit in the following pieces:
base frame assembly
upper column support with display console
handrails (left and right)
upper column support bracket covers (2 pieces) and rubber grommet
hardware kit and Owner’s Manual
CAUTION: This unit weighs over 230 pounds (105 kilograms). To prevent in-
jury to yourself or damage to the equipment, obtain appropriate assistance
before removing the unit from the pallet.
If any items are missing, contact your Precor Commercial Products Service Repre-
sentative at 1-888-665-4404.
STANDARD EQUIPMENT
The EFX546 incorporates the Precor SmartRate
®
and Heart Rate features into its
display console. Devices, such as FitLinxx
®
, that are CSAFE compatible, can also
be attached.
The Precor “touch” heart rate is standard and provides electrode strips, called
“grips, on the center handrails. When a user places his or her hands over the grips
and grasps the handrails, a heart rate is transmitted to the receiver.
Note: If a user does not wish to use the touch-sensitive hand grips, an optional
POLAR
®
chest strap can be purchased and worn. The chest strap transmits the
user’s heart rate to the display console’s receiver.
OTHER EQUIPMENT
Optional equipment available through your dealer includes:
Battery recharger
POLAR
®
chest strap.
If you are interested in obtaining Precor option kits for your unit, check with your
dealer. For customer support, see
Obtaining Service
on page 5.
Unpacking the EFX
®

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Precor EFX546 and is the answer not in the manual?

Precor EFX546 Specifications

Mechanical Specifications IconMechanical Specifications
cross ramp angle13 - 40 degrees (adjustable)
stride length18 inches (46 cm)
resistance levels1 - 20
Materials and Construction IconMaterials and Construction
framePowder-coated steel
Weight and Dimensions IconWeight and Dimensions
length80 inches (203 cm)
width30 inches (76 cm)
height62 inches (156 cm)
weight230 lbs (105 kg)
shipping weight340 lbs (155 kg)
