Precor EFX546 User Manual

page 7
COMMERCIAL PRODUCTS DIVISION
Important Safety Information ...........................................2
Hazardous Materials and Proper Disposal .............................. 3
Safety Approval ..................................................................... 3
RFI — Radio Frequency Interference ..................................... 4
European Applications ........................................................... 4
EFX
®
Self-powered Features .................................................. 5
Obtaining Service................................................................... 5
About this Manual .................................................................. 6
Unpacking the EFX
®
..................................................................................................
9
Standard Equipment............................................................... 9
Other Equipment .................................................................... 9
Hardware Kit .......................................................................... 10
Acquiring the Appropriate Tools .............................................. 10
Setting Up the EFX .........................................................11
Installation Requirements ....................................................... 11
Assembly Instructions ........................................................... 11
Supplying Power To the EFX546............................................. 17
Testing the Heart Rate Display ............................................... 18
Club Information.............................................................19
Changing the Club Settings .................................................... 19
Selecting the Language .......................................................... 20
Determining the Units of Measure .......................................... 20
Setting a Workout Time Limit.................................................. 21
Setting a Pause Time Limit .................................................... 21
Viewing the Odometer, Hours of Use,
Software Version, and Error Log ............................................. 21
Using CSAFE Standard Equipment ........................................ 22
The EFX
®
546 Display .....................................................23
Features on the Display Console............................................ 23
SmartRate
®
Display ............................................................... 24
Upper Display......................................................................... 24
Informational Displays Prior to Shutdown ............................... 24
Lower Display......................................................................... 25
Keys on the Display Console.................................................. 27
Keypad Tips ........................................................................... 27
Table of Contents

Precor EFX546 Specifications

Mechanical Specifications

cross ramp angle	13 - 40 degrees (adjustable)
stride length	18 inches (46 cm)
resistance levels	1 - 20

Materials and Construction

frame	Powder-coated steel

Weight and Dimensions

length	80 inches (203 cm)
width	30 inches (76 cm)
height	62 inches (156 cm)
weight	230 lbs (105 kg)
shipping weight	340 lbs (155 kg)
