Precor move beyond S3.15 User Manual

S3.15 Assembly and Maintenance Guide
page 26
1 2 3 4 5 6
4
Cable Adjustments
and Maintenance
Cable Adjustments and Maintenance
When the S3.15 is completely assembled, you need to
check the cables for proper tension. Obvious signs that
cable problems exist include:
✔ Top Cap Weight does not rest squarely on the top
weight of the Weight Stack.
✔ Cable rubs the inside edges of the pulleys.
✔ Excess slack exists in the cable.
✔ Weight Pin cannot be easily inserted in or
removed from each hole in the Weight Stack.
CAUTION: Take the time to perform the following
steps. If the cables do not have the proper tension
you could void the Precor Limited Warranty.

Precor move beyond S3.15 Specifications

Weight and Dimensions

length	72 inches (182 cm)
height	83 inches (211 cm)
width	51 inches (130 cm)
shipping weight	221 lb (100 kg)
