PRESONUS RM32AI - RM16 AI and RM32 AI Technical Specifications; Tape Inputs; Main Outputs; Headphone Output

56
5 RM Mixer Reference
5.4 RM16AI and RM32AI Technical Specications
StudioLive™ RM-Series Mixers
Owner’s Manual
5.4 RM16AI and RM32AI Technical Specifications
RM16AI RM32AI
Microphone Preamp
Input Type XLR Female, balanced, locking XLR Female, balanced, locking
Frequency Response to Direct Output (at unity gain) 20-40 kHz, ±0.5 dBu 20-40 kHz, ±0.5 dBu
Frequency Response to Main Output (at unity gain) 20-20 kHz, ±0.5 dBu 20-20 kHz, ±0.5 dBu
Input Impedance 1 kΩ 1 kΩ
THD to Main Output (1 kHz at unity gain) 0.005%, +4 dBu, 20-20 kHz,
unity gain, unwtd
0.005%, +4 dBu, 20-20 kHz,
unity gain, unwtd
S/N Ratio to Main Output (Ref = +4 dB, 20 kHz BW,
unity gain, A-wtd)
94 dB 94 dB
Common Mode Rejection Ratio (1 kHz at unity gain) 65 dB 65 dB
Gain Control Range (±1 dB) 0 dB to +65 dB 0 dB to +65 dB
Maximum Input Level (unity gain) +12 dBu +12 dBu
Phantom Power (±2 VDC) 48 VDC, switchable per channel 48 VDC, switchable per channel
Tape Inputs
Type RCA Female, unbalanced (stereo pair) RCA Female, unbalanced (stereo pair)
Maximum Input Level +12 dBu +12 dBu
Main Outputs
Type XLR Male, balanced XLR Male, balanced
Rated Output Level +24 dBu +24 dBu
Output Impedance 100Ω 100Ω
Mix Outputs
Type XLR Male, balanced XLR Male, balanced
Rated Output Level +24 dBu +24 dBu
Output Impedance 100Ω 100Ω
Headphone Output
Type ¼” TRS Female, active stereo ¼” TRS Female, active stereo
Maximum Output 120 mW/ch. @ 60Ω load 120 mW/ch. @ 60Ω load
Frequency Response 20 Hz – 20 kHz (± 0.5 dB) 20 Hz – 20 kHz (± 0.5 dB)
THD+N 0.01%, 1 kHz, max gain, 20 Hz BW, unwtd 0.01%, 1 kHz, max gain, 20 Hz BW, unwtd
S/N Ratio 96 dB, 1 kHz, max gain, 20 Hz BW, unwtd 96 dB, 1 kHz, max gain, 20 Hz BW, unwtd
System Crosstalk
Input to Output
-90 dB (Ref = +4 dBu
20 Hz-20 kHz, unwtd)
-90 dB (Ref = +4 dBu
20 Hz-20 kHz, unwtd)
Adjacent Channels
-87 dB (Ref = +4 dBu
20 Hz-20 kHz, unwtd)
-87 dB (Ref = +4 dBu
20 Hz-20 kHz, unwtd)
