Coach Exterior
16
BACK-UP CAMERA
An optional back-up camera is available which
provides the driver with visual assistance when
backing-up. Camera monitor is installed on the
dashboard L.H. side, on the windshield post. For
additional information, refer to "Controls &
Instruments".
110-120 VOLTS CONNECTOR
This connector is connected to the electric block
heater and uses a 110-120 VAC power source.
It is located near the engine compartment rear
doors release handle. (Refer to chapter “Starting
and Stopping Procedures”).
PRISE DE 110-120 VOLTS 06390
HUBODOMETER
An odometer is installed on the curb-side drive
axle wheel hub. The odometer calculates the
total distance in miles or kilometers (depending
on model installed) traveled by the coach since
manufacture, including factory road testing.
NOTE
It is normal for the hubodometer, the engine
ECM and the vehicle odometer to disagree on
the total mileage.
HUBODOMETER 13012
TRAILER HITCH
20 000 lb max. Gross trailer weight capacity
(optional)
Your vehicle may be equipped with a factory
installed trailer hitch which has been designed to
meet the following rating:
TRAILER HITCH
23337
• Maximum gross trailer weight: 20,000 lb
(9072 kg)
• Maximum tongue weight at 6 1/2 inches
(165 mm) or less from coupling receiver:
1,500 lb (680 kg)
DANGER
The draw bar and the ball used for towing the
trailer should be rated for 20,000 lbs capacity
or more.
