Controls and Instruments
68
DRIVER INFORMATION DISPLAY
The DID (Driver Information Display) is located
in the center of the instrument cluster. It displays
digital gauges, main menus and sub-menus that
provide necessary and important information to
the driver. The information available to the driver
depends on vehicle configuration, and whether
the vehicle is in operation or parked. For the list
of the available menus and sub-menus, refer to
“Driver Information Display Menus” in Other
Features chapter.
06746
The outside air temperature, fuel flow and the
odometer (Allison transmission) or the current
gear position (transmission I-Shift) are part of
the default display. You can replace the default
display by your selection of favorite gauges
using the Driver Information Display sub-menu
Favorite Display Setting. Refer to Other
Features chapter for more information.
06742
06743
1. Indicates first of six available menus (varies
by menu)
2. Clock
3. Odometer
4. Value or data (in this example, the engine oil
temperature)
5. Pictogram relevant to the displayed value or
data
6. Status bar active pictogram
7. Messages or available menus
Selecting a menu
Menus are placed in a cascade arrangement.
Use the steering wheel controls buttons to scroll
through them.
14069_3
To select a menu:
1. Press the ENTER or ESCAPE button to
display the list of available menus.
2. Use the UP/DOWN button to scroll up or
down through the menus.
To Next Page
